GB-8+3 Seats Tourist Car Electric Sightseeing Shuttle Bus

The GB-8+3 is a compact, eco-friendly electric sightseeing vehicle designed for efficient short-distance passenger transport. With an 11-seat capacity (8+3 configuration),  powered by an 8.2 kWh battery, it delivers a range of 70 km per charge and a maximum speed of 30 km/h—ideal for low-speed, stop-and-go operations. The 5 kW motor provides sufficient torque for gentle slopes up to 15%. Safety features include front ventilated disc brakes and rear drum brakes with vacuum assistance, complemented by a MacPherson front suspension and integral rear axle for stable, comfortable rides. it offers excellent energy efficiency and low maintenance costs.

This vehicle is perfectly suited for theme parks, resorts, large campuses, factory complexes, exhibition centers, airports, and retirement communities. It excels in moving small groups of visitors, staff, or residents over paved pathways, providing quiet, zero-emission mobility in pedestrian-friendly environments.

Share:

Vehicle Configuration

Passenger capacity11 seats
Max.Speed30km/h
Battery spec8*6V/170Ah Lead-acid Batteries
Endurance Mileage70km
Climbing Ability(loaded)15%
Min.Clearance140mm
Curb Weight1040kg
L×W×H4235x1510x2120mm
Braking Distance≤5.0m

Min.Turning Radius

≤4.5m

MotorAC5KW 48V
Controller48V 350A controller
Body|Chassis

High-strength composite material body

High-strength steel frame-type longitudinal beam chassis

TiresVacuum radial tires 165/70R13 with steel rims
Brake system

Front ventilated discs and rear drum hydraulic dual circuit brakes + handbrake parking with

vacuum-assisted braking system

SteeringDual push rack and pinion steering + electric power steering system
SeatsPU car special seat, ergonomic

Windshield

Automotive-grade laminated glass

Weight 1040 kg
Dimensions 424 × 151 × 212 cm
