Vehicle Configuration
| Controller | Curtis AC Controller 72V 300Ah, Amrican Brand | ||
| Motor | KDS 72V 7.5kw ACIM MOTOR, made by Japan Nidec Corporation’s subsidiary | ||
| Batteries | Trojan T-875 9*8V maintenance free batteryAC controller 60V | ||
| Tires | 175/60R14 TIRE, Aluminum Rim | ||
| Transaxle | Heavy Duty Axle with differential gearcharger | ||
| On board Charger | 72V 30A Intelligent Onboard Charger | ||
| Passenger Capacity | 18 | ||
| Overall Dimensions | 5980*1845*2020mm | ||
| Max. Loading Weight | 1440 kgs | ||
| Curb Weight (with batteries) | 1420kgs | ||
| Endurance Mileage | 80~100km |
| Climbing Capacity (full load) | 30% | ||
| Max. Speed | 35km/h | ||
| Min Turning Radius | 5.7m | ||
| Ground Clearance | 170mm | ||
| Front / Rear Track | 1210/ 1200mm | ||
| Wheelbase | 3510mm | ||
| Body | Fully elastic flame retardant PP Plastics | ||
| Chassis | High Strength Steel Alloy Frame with E-Coating & Power Coating | ||
| Brake System | Vacuum booster +4 wheel hydraulic brake, more safe than basic hydraulic | ||
| Steering System | EPS (Electric power steering) system , lighter than mechnical rack and pinion | ||
| Suspension | Mcpherson Strut Independent spring suspension |
