Vehicle Configuration
| Passenger capacity | 2 seats | ||
| Max.Speed | 30km/h | ||
| Battery spec | 8*6V/170Ah Lead-acid Batteries | ||
| Endurance Mileage | 90km | ||
| Climbing Ability(loaded) | 20% | ||
| Min.Clearance | 170mm | ||
| Curb Weight | 995kg | ||
| L×W×H | 3250x1520x2120mm | ||
| Braking Distance | ≤5.0m | ||
Min.Turning Radius | ≤4.5m |
| Motor | AC5KW 48V | ||
| Controller | 48V 450A controller | ||
| Body|Chassis | High-strength composite material body High-strength steel frame-type longitudinal beam chassis | ||
| Tires | Vacuum meridian microcar tire, specification: 185/70-R13 | ||
| Brake system | Front ventilated discs and rear drum hydraulic dual circuit brakes + handbrake parking with vacuum-assisted braking system | ||
| Steering | Dual push rack and pinion steering | ||
| Seats | PU car special seat, ergonomic | ||
Windshield | Automotive-grade laminated glass |
